4-ways distributor with wall connections for copper

  • 4-ways distributor with wall connections for copper
  • Scheda tecnica - 4-ways distributor with wall connections for copper
  1. 4-ways distributor with wall connections for copper
  2. Scheda tecnica - 4-ways distributor with wall connections for copper
Art. 3856

4-ways distributor with wall connections.
Euroconus connections for copper, Pex and multilayer pipe
For bitube system.
Supply ccoefficient 100%

Print datasheet

Items

Code Size (D) Smooth D1 H I L Pack
3856000400 1/2" 3/4" 35 37 112 10
Smooth
  • Yellow
  • Chrome
  • Nickel
  • White

Max working temperature: 100°C
Max working pressure: 10 bar
Body in forged brass
Threads: ISO 228
Thermostatic head attachment: M30x1,5
Suitable for fittings for copper, PEX or multilayer piping
Available with thermostatic head: art.400 -art.400A
Allowed fluids: water (Glycole max percentage: 50%)
The mono pipe valves with four outlets are supplied complete with brass supply feeler
