Prolunga MF
Art. 7652
Prolunga MF
Articoli
| Codice | Dimensione (D) | Finitura | Imballo | I | L |
| 076520310C | 3/8" | 25 | 10.0 | 10.0 | |
| 0765203150 | 3/8" | 25 | 10.0 | 15.0 | |
| 076520315C | 3/8" | 25 | 10.0 | 15.0 | |
| 0765203200 | 3/8" | 25 | 10.0 | 20.0 | |
| 076520320C | 3/8" | 25 | 10.0 | 20.0 | |
| 0765203250 | 3/8" | 25 | 10.0 | 25.0 | |
| 076520325C | 3/8" | 25 | 10.0 | 25.0 | |
| 0765203300 | 3/8" | 25 | 10.0 | 30.0 | |
| 076520330C | 3/8" | 25 | 10.0 | 30.0 | |
| 0765203400 | 3/8" | 25 | 10.0 | 40.0 | |
| 076520340C | 3/8" | 25 | 10.0 | 40.0 | |
| 0765203500 | 3/8" | 25 | 10.0 | 50.0 | |
| 076520350C | 3/8" | 25 | 10.0 | 50.0 | |
| 0765204100 | 1/2" | 50 | 11.0 | 10.0 | |
| 076520410C | 1/2" | 50 | 11.0 | 10.0 | |
| 0765204150 | 1/2" | 50 | 11.0 | 15.0 | |
| 076520415C | 1/2" | 50 | 11.0 | 15.0 | |
| 0765204200 | 1/2" | 25 | 11.0 | 20.0 | |
| 076520420C | 1/2" | 25 | 11.0 | 20.0 | |
| 0765204250 | 1/2" | 25 | 11.0 | 25.0 | |
| 076520425C | 1/2" | 25 | 11.0 | 25.0 | |
| 0765204300 | 1/2" | 25 | 11.0 | 30.0 | |
| 076520430C | 1/2" | 25 | 11.0 | 30.0 | |
| 0765204400 | 1/2" | 25 | 11.0 | 40.0 | |
| 076520440C | 1/2" | 25 | 11.0 | 40.0 | |
| 0765204500 | 1/2" | 10 | 11.0 | 50.0 | |
| 076520450C | 1/2" | 10 | 11.0 | 50.0 | |
| 0765204600 | 1/2" | 10 | 11.0 | 60.0 | |
| 076520460C | 1/2" | 10 | 11.0 | 60.0 | |
| 0765205100 | 3/4" | 50 | 12.0 | 10.0 | |
| 076520510C | 3/4" | 50 | 12.0 | 10.0 | |
| 0765205150 | 3/4" | 25 | 12.0 | 15.0 | |
| 076520515C | 3/4" | 25 | 12.0 | 15.0 | |
| 0765205200 | 3/4" | 25 | 12.0 | 20.0 | |
| 076520520C | 3/4" | 25 | 12.0 | 20.0 | |
| 0765205250 | 3/4" | 25 | 12.0 | 25.0 | |
| 076520525C | 3/4" | 25 | 12.0 | 25.0 | |
| 0765205300 | 3/4" | 25 | 12.0 | 30.0 | |
| 076520530C | 3/4" | 25 | 12.0 | 30.0 | |
| 0765205400 | 3/4" | 25 | 12.0 | 40.0 | |
| 076520540C | 3/4" | 25 | 12.0 | 40.0 | |
| 0765205500 | 3/4" | 25 | 12.0 | 50.0 | |
| 076520550C | 3/4" | 25 | 12.0 | 50.0 | |
| 0765206100 | 1" | 30 | 15.0 | 15.0 | |
| 076520610C | 1" | 30 | 15.0 | 10.0 | |
| 0765206150 | 1" | 30 | 15.0 | 15.0 | |
| 076520615C | 1" | 30 | 15.0 | 15.0 | |
| 0765206200 | 1" | 30 | 15.0 | 20.0 | |
| 076520620C | 1" | 30 | 15.0 | 20.0 | |
| 0765206250 | 1" | 20 | 15.0 | 25.0 | |
| 076520625C | 1" | 20 | 15.0 | 25.0 | |
| 0765206300 | 1" | 10 | 15.0 | 30.0 | |
| 076520630C | 1" | 10 | 15.0 | 30.0 | |
| 0765206400 | 1" | 10 | 15.0 | 40.0 | |
| 076520640C | 1" | 10 | 15.0 | 40.0 | |
| 0765206500 | 1" | 10 | 15.0 | 50.0 | |
| 076520650C | 1" | 10 | 15.0 | 50.0 |
Finitura
- Giallo
- Cromo
- Nichel
- Bianco
Temperatura d'esercizio: 0°C -100°C
Pressione massima d'esercizio : 10 bar
Filetti maschio: ISO 7/1
Filetti femmina: ISO 228
