Safety valve male connection, with manometer connection
Art. 447C
Safety valve male connection, with manometer connection
Items
| Code | Version | Size (D) | Smooth | Handle | Pack | I | L | h |
| 447C000402 | 2,5 Bar | 1/2" | Plastic | 10 | 22.0 | 25.0 | 65.0 | |
| 447C000403 | 3 Bar | 1/2" | Plastic | 10 | 22.0 | 25.0 | 65.0 | |
| 447C000406 | 6 Bar | 1/2" | Plastic | 10 | 22.0 | 25.0 | 65.0 |
Smooth
- Yellow
- Chrome
- Nickel
- White
Working temperature: 0-110°C (solar 140°C)
Max working pressure: 10 bar
Opening overpressure: 10%
Closing differential: 20%
Tolerance: 10%
Body in forged brass
Threads: ISO 228
Made in accordance with the safety requirements laid down in European Directive 2014/68/EU (PED)
